20
Full Scart
Pin No. Description Pin No. Description
1 Audio Output Right 12 N.C.
2 Audio Input Right 13 GND(Red)
3 Audio Output Left 14 GND(Blanking)
4 GND(Audio) 15 Red Input
5 GND(Blue) 16 RGB Switching Control
6 Audio Input Left 17 GND(Video Input & Output)
7 Blue Input 18 GND(RGB Switching Control)
8 Switch Signal Input (Fast Blanking) 19 Video Output(Composite)
9 GND(Green) 20 Video Input(Composite)
10 N.C.
21
Common Ground
11 Green Input
3.2 Video/Audio Signal
● TV RF input system - Aerial or cable should support PAL/SECAM/DVB-T
● TV RF input level - 10mV (80dBuV) typical, 30dBuV ~ 100dBuV receiving capability, terminated with input
impedance of 75Ω.
● CVBS input - 1000mVpp (including 300 mV sync level), terminated with input impedance of 75Ω.
● S-Video input - Y: 1000mVpp (include sync), C: 300mVpp terminated with Input Impedance of 75Ω.
● Component video input - Y: 1000mVpp (include sync), PbPr: 700mVpp terminated With Input impedance of 75Ω.
Support 480i/p, 576i/p, 720p, 1080i at 50Hz or 60Hz refresh rate.
● Audio input - Sensitivity 500mV (rms). For rated power, the amplifier should be able to handle input
signal up to 2.0V, input impedance >10KΩ.
● SCART input / output - Full SCART, includes RGB in, CVBS (audio L/R) in/ (TV out).
Half SCART includes S-Video in, CVBS (audio L/R) in/ (TV out).
● HDMI (High Definition Multimedia Interface)-
Support 480i /480p, 576i/576p, 720p, 1080i format with HDCP
Digital interface with 4 channels TMDS signal
● CI Slot - PCMCIA card 5V input.
● PC VGA input - 700 mV input level, TTL level sync, RGB in, 75Ω impedance.
● PC Audio input - 500 mVrms input level, impedance > 10 kΩ.
● Headphone output - 4mW (Typ.) at 32Ω, impedance between 8 - 600Ω.
● SPDIF output - Level: 0.5V+/- 0.1V at 75, Square Wave. SPDIF output sync SCART audio out.
● Amplifier output - 5 W+/-10%
● Speaker - 8Ω
