Bush A632N - Page 74

74
A632N
Mechanical Parts List Screws List
No. Part No. Description
1 A34T1050 GMB1L0130 BEZEL
2 078G 522 1B Y SPK
3 A33T0536 GME1L0100 KEY HOLDER
4 A33T0537 QV 1L0100 KEY PAD
5 A33T0562 ED 1C0100 IR LENS
6 A33T0563 1 1C0100 POWER LENS
7 PWTV9NE1GQN6 POWER BOARD
8 A15T0560101CKD 32TV-BASE-SUPPORT-G3
9 A15T0559101CKD 32TV-VESA-BKT-G3
10 750TVG320EBC12N000 PANEL
11 Q15T0713101 BKT_MPCB_SUPPOT_R
12 756TQ9CB 2B122 02 MAIN BOARD
13 A34T1610 GM 1L0130 COVER IO SIDE-26/32
14 A34T0974 GM 2L0130 REAR COVER 32-9A
15 A34T1612 GM 1A0100 COVER IO BACK-26/32
16 Q37T0134011 HINGE
17 A34T1051 GM 1L0100 BASE
18 A15T0643101CKD 32TV BKT_BASE-1
19 Q12G6300 25 1 RUBBER FOOT
No. Type Part No. Description Q’ty
BASE SUPPORT / PANEL*5
1 M4*6 0M1G 940 6120
PANEL / VESA *4
9
2 Q3*8 0Q1G 130 8 47 CR3 BASE BKT / BASE*6 6
3 M3*6 0M1G 930 8 47 CR3 BACK COVER IO / MAIN BOARD*2 2
POWER BOARD/PANEL*5
4 M3*8 0M1G1730 6120
MAIN BOARD/PANEL*5
10
5 M4*12 0M1G 940 12 47 CR3 HINGE/BACK COVER*2 2
6 M4*10 0M1G1740 10120 HINGE BKT/PANEL*2 2
7 Q3*8 0Q1G 930 8 47 CR3
MAIN BOARD*4
MIAN BOARD/BACK COVER*1
SIDE COVER/MAIN BOARD*2
7
8 Q3*6 0Q1G 930 6120 KEY HOLDER/KEY BOARD*2 2
9 Q4*16 0Q1G 940 16 47 CR3 BEZEL/BACK COVER*12 12
10 Q4*10 Q01G6070 1
SPK/BEZEL*4
PANEL/BEZEL*2
6
11 M3*10 0Q1G1030 6120 IR BOARD/BEZEL*1 1
12 M3*10 0M1G1730 10120 POWER BOARD/AC SOCKET 1
13 Q4*12 0Q1G 940 12 47 CR3
BASE BKT/HINGE*4
PANEL/BEZEL*2
6
