AX27 Clamshell Tent

The Bush Company www.thebushcompany.com

AX27 Instructions v2.0.docx Last Updated: 11/09/2023 11:51:00 AM

4.2.1 Option 1 – Fitment Bracket Outside Extrusion

4.2.2 Option 2 – Fitment Bracket Inside Extrusion

4.2.3 Option 3 – Fitment Bracket Inside Extrusion

FITMENT BRACKETS ON THE

OUTSIDE OF THE TENT

FOOT EXTRUSIONS

FITMENT BRACKETS ON THE

INSIDE OF THE TENT FOOT

EXTRUSIONS

MOUNTING BOLTS INSERT INTO

CENTRAL CHANNEL OF

THE TENT

FOOT EXTRUSIONS
