42”&47” LCD TV BAUER A642F&A647F
78
51 0Q1G 330 6 47 CR3 SCREW(MAIN BOARD/SIDE IO COVER) 2
52 0M1G 330 6 47 CR3 SCREW(MAIN BOARD/SIDE IO COVER) 1
53 0Q1G 130 6120 SCREW(MAIN BOARD/SHIELDING) 4
54 0M1G 130 6120 SCREW(MAIN BOARD/SHIELDING) 2
55 A34T1268 1101A REAR_COVER 1
56 0Q1G 940 14 47 CR3 SCREW(REAR_COVER/BEZEL) 14
57 A33T0628 1101A POWER_CORE 1
58 A33T0627 1101A AC_HOLDER 1
59 0Q1G 340 10 47 CR3 SCREW(AC_HOLDER/REAR_COVER) 1
60 0Q1G 130 8 47 CR3 SCREW(REAR COVER/BKT) 2
61 A34T1270 1101A STAND 1
62 A34T1269 1101A0130 BASE 1
63 A33T0680 1101A SWIVEL_WASHER_TOP 1
64 A15T0705101 BASE_BKT 1
65 A33T0681 1101A SWIVEL_WASHER_MID 1
66 A15T0706101 SWIVEL_WASHER_BOT 1
67 0Q1G 940 14 47 CR3 SCREW(SWIVEL_WASHER_BOT/STAND) 7
68 0Q1G1030 10120 SCREW(BASE_BKT/BASE) 8
69 0Q1G 940 14 47 CR3 SCREW(REAR_COVER/PANEL-MAIN-BOT-BKT) 4
A647F
Item Haier Part No. Description Q’TY
1 A34T1259 1101A0130 BEZEL 1
2-1 A33T0631 1101A KEY PAD COVER 1
2-2 A33T0625 1101A KEY 1
2-3 A33T0626 1101A KEY PAD 1
2-4 KEPF9QA5 KEY BOARD 1
3 A33T0635 1101A LIGHTING LENS 1
4 A33T0624 1101A IR_LENS 1
5 IRPF9QA5 IR BOARD 1
6 078G0120 7 Y SPEAKER 2
7 750TVG470UNA11N000 PANEL 1
8
A15T0731101 BKT-HOLDER-TOP
2
9
A15T0732101
BKT-SIDE 2
10 A15T0733101 BKT-HOLDER-BOT 2
11 A15T0741101 BKT-SUPPORT-RIGHT 1
12 A15T0740101 BKT-SUPPORT-LEFT 1
13 A15T0738101 BKT-STAND-SUPPORT 1
14 A15T0734101 BKT-METAL-UP 1
15 A15T0734201 BKT-METAL-DOWN 1
16 A15T0737101 BKT-PLATE 1
17 A15T0735101 BKT-HOLDER-LEFT 1
18 A85T0175101 SHIELD_INVERTER 1
19 A15T0736101 BKT-HOLDER-RIGHT 1
20 A15T0739101 BKT-STAND 1
21 ADTV82427AA4 ADAPTER BOARD 1
22 A85T0176101 SHIELDING 1
23 A34T1253 GM 1K0100 SIDE IO COVER 1
24 A85T0170101 SHIELDING-A 1
25 A85T0170101 SHIELDING-B 1
26 756TQ9CB 2B032 MAIN BOARD-CBPF92JBA1S 1
