Bush BT-201 - Controls and LED Display Overview; Front Panel Controls and Rear Sockets; LED Display Indicators

Controls and Indicators / LED Display
3
1 2 3 4 5 6 7 8 9
10 11 12
13 14 15
16 17 18 19
Controls and Indicators
1. POWER ON-OFF/ALARM OFF BUTTON
2. SOURCE BUTTON
3. MEMORY/ SET CLOCK BUTTON
4. ALARM 1 ON-OFF SET BUTTON
5. SNOOZE / SLEEP / DIMMER BUTTON
6. ALARM 2 ON-OFF SET BUTTON
7. SKIP BACK BUTTON
8. MEMORY UP/PLAY/PAUSE BUTTON/ PAIR BUTTON
9. SKIP FORWARD BUTTON
10. VOLUME KNOB
11. SPEAKER
12. SET KNOB
13. BATTERY COMPARTMENT (BOTTOM OF UNIT)
14. DISPLAY
15. RATING LABEL (BOTTOM OF UNIT)
16. LINE IN JACK
17. DC POWER INPUT
18. USB CHARGING SOCKET
19. FM ANTENNA
LED Display
