Parts Identification
9
Extension Tube
This vacuum cleaner incorporates an
adjustable extension tube.
To extend the tube, push the locking
catch forward and pull the tube to the
desired length. Release the locking
catch to lock the tube into position.
Crevice tool/brush
The crevice tool can be used to clean
hard to reach places.
Attach it directly to the handle for
greater control, alternatively, attach to
the extension tube for greater reach.
The crevice tool is tted with a small
brush that rotates forwards and clocks
into position for use.
The brush can be removed by rotating
the brush back until it clicks into the
storage position.
Crevice tool storage xings
A storage xings is provided to attach
the crevice tool to the hose handle.
Refer to the crevice tool storage picture
on page 8.
Crevice tool
Brush use
Locking
catch
Attach
here
