II Distribution box in the motor compartment
2.1. Connectors code illustration
2.2. Fuses illustration for distribution box in the motor compartment
F1-23Master fuse
reservation
F1-22Master fuse
F1-25Power
switch
F1-24Door &
window motors
Distribution box
in the motor
compartment
K1-5High-spe
ed cooling fan
relay
K1-3 Rear
defroster
reply
K1-2
Compressor
relay
K1-1 front
blower
relay
K1-4High-
speed radiator
relay
