F3DM Owner’s Manual
Instrument Panel Cable Plug-in Relay
Relay
1 Width-indicator light relay
2 Backup light relay
3 Front fog light relay
4 Blower relay
Floor Cable Plug-in Relay
Relay
1
Air conditioner contactor
relay
2 DC contactor relay
3
Positive pole contactor
relay
4
Pre-charging contactor
relay
5
Negative pole contactor
relay
6 Charging contactor relay
High-voltage Cable
High-voltage Cable
