BYD Suri Owner‘s Manual
Specification of Parts8-8
The fuse position is marked with
symbol on the fuse nameplate. For
the fuse on your vehicle, please
refer to the table on this page.
473QE
No. Amperage
Components or
Circuits under
Protection
1 20A Door lock motor
2 7.5A Interior lights
3 10A
Multiple integrated
control unit
4 15A
Audio and video
systems
5 15A
Cigarette lighter and
vehicle spare power
6 7.5A Rear fog light
7 20A Reserved fuse
8 20A
Driver's power seat
inclination
adjustment motor
and rear
up-and-down
adjustment motor
(8-way adjustable)
9 30A Reserved fuse
10 20A
Driver's power seat
slide (back and forth)
No. Amperage
Components or
Circuits under
Protection
adjustment motor
and front
up-and-down
adjustment motor
(8-way adjustable)
11 20A Reserved fuse
12 7.5A Oxygen sensor
13 7.5A Axial shaft lock
14 10A IG2 power
15 20A Skylight motor
16 20A
Driver‘s side glass
lifter motor
17 20A
Right rear door glass
lifter motor
18 20A Right front door
glass lifter motor
19 20A Left rear door glass
lifter motor
20 7.5A Cigarette lighter,
vehicle spare power
relay, audio device
and direction display
of interior rear view
mirror
21 15A Motor control module
22 20A Starter
No. Amperage
Components or
Circuits under
Protection
23 30A Main relay of EFI I
24 15A Diagnostic apparatus
power and oil pump
motor
25 15A Main relay of EFI II
26 15A Engine ECU
27 10A EPS
28 15A Washing motor
29 7.5A Heater and defroster
of exterior rearview
mirror
30 15A EPB
31 7. 5A Relay control module
32 15A Airbags
33 30A Wiper system
