Measurement unit and protective holder
1 Mode scroll wheel: used to turn the unit on and for menu selection
2 Display for user guidance and displaying measurement values
3 Green signal lamp: measurement active; red: error
4 Operate button (measurement button): used to activate
measurements
5 Protective holder
6 Calibrating standard
7 Mark for the measurement aperture
8 Interface for connecting to a PC
9 Thickness sensor
1
2
4
3
7
8
5
6
5 Control elements
