- Unscrew transformer cover at the base of the transformer
- Connect mains wire to transformer at the base as indicated in
figure A as indicated above
- Twin bell wire from the bell push should be wired to terminals 0
& 2.
Warning:
ALWAYS TURN OFF THE ELECTRICAL SUPPLY BEFORE STARTING
ANY WORK IF IN DOUBT CONSULT A QUALIFIED ELECTRICIAN. FOR
INDOOR USE ONLY.
Output: 8volt 1amp
Input: 220/240v
Transformer Cover
Lid
Input:
220/240v
