C-LOGIC 420-TC User Manual

10
Key operation
No. Symbol Description
A
Rotary button
Clockwise rotation for increasing the value
B
Rotary button
1. Under turn on state, a short press switches between manual and
automatic mode.
2. Under turn on state, a long press (3 seconds) allows to enter in the
setting screen.
3. In other screens, it acts as con rm key.
C
Rotary button
Anticlockwise rotation for decreasing the value
D
Short press for power on / off.
Long press (3 seconds) for screen locking or unlocking.
Main setting screen
Modo Explicación
Automátic
mode
Una pulsación corta de la tecla
activará el modo automático, mostrando el
icono en pantalla.
Manual mode
Other short press of the rotary button enables the manual mode, displaying the
icon. Under this mode, it is possible to adjust the set temperature by rotating
the button clockwise (increasing the temperature) or anticlockwise (decreasing
the temperature). When room temperature is lower than setting temperature,
the heating contact will be closed and the cooling contact will be opened ( icon
is displayed) and when room temperature is higher than setting temperature,
the heating contact will be opened and the cooling contact will be closed ( will
disappear)
Temporary
manual mode
Under automatic mode and unlock state, when rotating the button to adjust the
temperature, it will enter into temporary manual mode. This temporary mode
works to next interval when it will return to the automatic mode. If you want
to return to automatic or manual mode, please press the button once or twice
respectively.
Press the rotary button
for 3 second for entering in the setting screen. Rotates the button to
select the required icon and press the button to con rm the access to that setting.
Holidays
mode
After entering into setting screen, rotate rotary button to select
icon and
press the key to enter into holiday mode setting. Select ON in order to enable
the holiday mode. Then adjust the number of days (countdown until returning to
automatic mode) by rotating again the rotary key and press the key to con rm.
Finally and exit to the main screen. To cancel the holiday mode return the holiday
mode setting, select OFF and press the key to con rm.
