How to use the PLC Compatibility and Connection Charts
1.) Find the PLC Family being used.
2.) Find the particular PLC model in the PLC family.
3.) Determine the cable and other components, manufactured or user constructed, are required.
Example:
PLC Compatibility & Connection Chart
PLC C-more Micro-Graphic Panel
Family CPU PLC Port & Type
Panel to PLC Cabling Components Required for
Specific Port and Protocol being used.
External DC Power Supply
Using panel’s Port2
DB 15-pin - female
Protocol(s)
Supported
Components &
Network Type
CLICK
all versions
Port 1
RJ12 - 6 pin
AutomationDirect
Modbus (CLICK)
EA-2CBL
RS-232
Direct LOGIC
DL05
all versions
Port 1
RJ12 - 6 pin
K-sequence,
Direct NET,
Modbus RTU
EA-2CBL
RS-232
Port 2
RJ12 - 6 pin
D0-DCM
Port 1
RJ12 - 6 pin
K-sequence,
Direct NET,
Modbus RTU
EA-2CBL
RS-232
Port 2
DB15HD
(female)
EA-2CBL-1
RS-232
* See Diagram 1
RS-422
Modbus RTU
* See Diagram 2
RS-485
Modbus only
