C-SCOPE CS4ZX User Manual

4
Controls C-Scope CS4ZX
Diagram 1
A
T
S
I
B
C
D
E
H
G
F
J
K
L
CS4ZX
N
O
P
Q
R
M
A Battery Compartment
B Din Plug & Socket
C Upper Stem & Handle Grips
D Stem Connecting Nut
E Lower Stem
F Search Head Lugs
G Search Head Fastener
H Cable
I Frequency Select Switch
(Both Modes)
J All Metal M
ode/Discrimination
(Motion Mode)
K Meter (Both Modes)
L Power On/Off & Sensitivity
M Notch Discrimination
(Motion Mode)
N Notch Discrimination
Accept/Reject (Motion Mode)
O Mode Select
P Meter Function select
Q Beach/Inland Select
(Non Motion Mode)
R
Variable Ground Control
(Non Motion Mode)
S Battery Charge Socket Cover
T Headphone Socket Cover

C-SCOPE CS4ZX Specifications

General

Brand	C-SCOPE
Model	CS4ZX
Category	Metal Detector
Language	English
