CXL4 and DXL4 Locators: Technical Specifications

Controls On/Off Switch: Spring loaded trigger switch under handle

Function Select Switch (FOUR position): P. Power Mode; R. Radio Mode; G. Generator Mode; A. All Scan Mode

Sensitivity Control

For DXL4 only Depth Button. Push button for live display of depth

Audio Indication Removable and user replaceable loudspeaker module

Visual Indication Multi-segment Liquid Crystal Display indicating:

Signal Strength; Mode selected; AlarmZone™; Battery Condition; Self Test Indicator

For CXL4-DBG and DXL4-DBG only, GPS signal detected, Bluetooth™ activated

For DXL4 only in Generator Mode, Depth Measurement

Data Logging Internal capacity for storing over 12 months of data (in normal use) logged once per second

Data logged includes Time/Date, Mode, Sensitivity Level, Received Signal Level, Frequency, Depth, Self Test Result, Swing Indicator

For CXL4-DBG and DXL4-DBG only, GPS position

Bluetooth™ Bluetooth 2.1

GPS GPS/QZSS/GLONASS/SBAS

Data Connector Standard USB Mini B connector in battery compartment. USB 2.0 Compatible

Self Test Automatic Daily Self Test

Swing Indicator Audio beep to indicate incorrect use of the Locator

Generator Mode Frequencies Simultaneous 131,072Hz and 32,768Hz

Construction Case moulded from high impact plastic. Designed to withstand 1m (3’3”) drop onto a hard surface

Weight (including batteries) 2.65kg (5 lb 13 oz)

Dimensions 720mm x 280mm x 65mm (28.3” x 11” x 2.5”)

Performance Locate Accuracy: better than 10% of depth

Depth Accuracy: ±5% @ 1m (3’3”)

Line Depth Measurement Range: 0.1m to 9.99m (4” to 32’)

Line Depth Resolution: 0.01m (0.4”)

Sonde Depth Measurement Range: 0.1m to 9.99m (4” to 32’) depending on Sonde type

Sonde Depth Resolution: 0.01m (0.4”)

Battery Type Internal 8 x ‘AA’ (LR6) cells (either alkaline non-rechargeable or NiMH rechargeable)

Battery Life 40 hours intermittent use at 20ºC (68ºF) using alkaline cells

IP Rating 65

Notes: Performance figures stated can be affected by site parameters such as ground conditions, temperature, and strong electromagnetic fields.

Specification may be subject to change.

All C.Scope Locators are in compliance with the essential requirements and other relevant provisions of Council Directive 2014/30/EU (EMC).

Compliance has been demonstrated by testing representative samples to the relevant harmonised standards.

All C.Scope Locators comply with the essential requirements and other provisions of Council Directive 2011/65/EU (RoHS).
