Instruction Booklet7-Series
Tall Back Rotating
Seat-Sliding
Adjustment
Tilting Armrest
Seat Rotation
13" Rear Wheels
Mirror
Seat
Slide
Tiller Angle
Adjustment
Front Basket
Throttle
Turn Signals
Head Light
Front Bumper
11" Front Wheels
Self-diagnostic
Warning Light
Power Reserve Indicator
Amrest Width
Adjustment
Thumbscrews
Rear Light
and Turn
Signals
Rear
Bumper
Free-Wheels LeverAnti-Tip Wheels
Warning
button
Horn button Speed Control Knob
Figure 1 - HS-745 Front View
Figure 2 - HS-745 Joystick
Figure 3 - HS-745 Rear View
IDENTIFICATION OF PARTS
Before attempting to drive this scooter on your own, it is important that you familiarize
yourself with the controls, and how to operate them.
