DISASSEMBLING YOUR SCOOTER
C.T.M. 3-series's compact and light weight design fits easily into the trunk or back seat
of most cars for transportation. No tools are necessary to disassemble scooter.
Please follow these steps:
Remove seat by releasing Seat Rotation Lever and then. lift off
.(See Fig. 4)
Remove Rear Shroud off of the Scooter.(See Fig. 5)
Remove Battery Fixing Velcro.
(See Fig. 6)
Detach Battery Power Plugs.(See Fig. 7)
Remove two Batteries.
(See Fig. 8)
Figure 5
Figure 5
Figure 6
Figure 6
Figure 7
Figure 7
Figure 8
Figure 8
Figure 4
Figure 4
