Instruction Booklet5-Series
14
ASSEMBLING YOUR SCOOTER
To assemble the scooter, you can repeat the disassembly directions in reverse.
A
bbreviated directions are given below. Refer to the Figures on pages 12 - 13 to
locate the parts.
1.Use the Tiller Adjustment to move the tiller up out of the way.
2.Tilting the rear end to a horizontal position, insert the scooter frame tube of the front
end into the rear section first, making sure that the locking pins are removed.
3.Slide the two sections of the unit together until the front half reaches its limit.
4.Insert the two locking pins into their corresponding holes. Both locking pins must be
fully inserted whenever the scooter is assembled.
5.Place batteries, use Velcro to fix the position and attach the battery power plugs.
6.Plug the main wiring harness.
7.Place rear shroud.
8.
Pull Seat Rotation Lever to place seat on seat post. Release lever to lock seat in position.
