Coas

tal Amusements Inc. | Ring Toss

EXPLODED DIAGRAMS

ITEM #

Part No

. DESCRIPTION QTY.

1 RT-SM-67 LIFTING

TRAY 1

2 RT-SCP-17 LIFTING

TRAY DECAL SET 2

3 RT-KIT-RT-BOTT

LE BOTTLE ASSEMBLY 46

4 RT-SCP-01 RING SCREEN 1

5 CA-SWI-RT-SPDT1

5A TRAY ACTION MICROSWITCH 1

6 RT-SM-30 MICRO

SWITCH SUPPORT 1

7 CA-BRG-RT-G

ROMMET NYLON 5/8" BEARING FOR 11/16" INSERT 4

8 RT-SM-68 SNAP

IN BEARING BRACKET 4

9 CA-MOT-RT-ACTUATOR LINEAR ACTUATOR "B" STYLE GEARBOX 1
