Parts List
# Part Number Description Qty
1
26.401.94 Engine, Green 1
2
122.190005.00 Rubber, Fore-Cover, B 1
3
122.190005.01 Rubber, Fore-Cover, A
1
4
123.191100.19
Rotor Assembly, Al,
120 mm, No DC
1
5
2.08.022 Flange Bolt M8×242
1
6
1.96.08 Washer Ø8
1
7
1.7244.08 Spring Washer Ø8
1
8
123.191200.23
Stator Assembly, Al,
120 mm, No DC
1
9
123.191002.01 Stator Cover
1
10
122.190002.00 End Housing
1
11
2.08.065 Flange Bolt M6×168
4
12
1.97.1.06 Washer Ø6
4
13
1.93.06 Spring Washer Ø6
8
14
122.190300.00 Carbon Brush Assembly
1
15
122.190004.01 Pinch, Carbon Brush
1
16
1.93.05 Spring Washer Ø5
3
17
1.5783.0516 Bolt M5×16
3
18
1.97.1.05 Washer Ø5
2
19
122.190200.03 AVR (2KW CPE)
1
20
1.16674.0516 Flange Bolt M5×16
2
21
122.190003.00.94 Generator End Cover, Green
1
22
1.16674.0512.2 Flange Bolt M5×12
7
23
122.190400.00 Terminal Block
1
24
122.190018.00 Bracket I, Muffler
1
25
1.16674.0820 Flange Bolt M8×20
3
26
122.190018.01 Bracket II, Muffler
1
27
1.5789.0612 Flange Bolt M6×12
7
28
1.9074.4.0514
Screw And Washer Assembly
M5×14
2
29
46.101503.08 Plate, Spark Arrester
1
30
46.101300.08 Spark Arrester Assembly
1
31
26.101000.00 Muffler Assembly
1
32
23.102000.03.2 Muffler Cover
1
33
1.6175.08 Nut M8
2
34
1.93.08 Spring Washer Ø8
2
35
1.848.08 Washer Ø8
2
36
26.100001.00 Muffler Gasket
1
37
23.090006.21 Holder, Air Cleaner
1
38
1.5789.0608 Flange Bolt M6×8
1
39
23.070011.04 Pipe, Fuel (6.1 in.)
1
40
2.06.007 Clamp (Ø8×b6)
2
41
122.070400.05 Fuel Cock
1
42
122.071000.05.94 Fuel Tank, Green
1
43
122.070015.01 Mount Vibration, Fuel Tank
4
44
2.03.004 Washer (Ø24×Ø6.5×1.5)
4
45
1.5789.0620.2 Flange Bolt M6×20
4
46
23.070301.00 Fuel Filter
1
47
24.070100.00 Fuel Tank Cap
1
48
24.070014.05
Pipe, Reversal Valve,
630 mm
1
49
24.070030.00 Hole, Breather Tube
1
50
2.06.006 Clamp (Ø7×Ø1)
1
51
24.070800.00 Reversal Valve
1
# Part Number Description Qty
52
1.819.0510 Screw M5×10
2
53
122.072000.00 Fuel Meter Assembly
1
54
152.200702.00 Cover, Handle
1
55
122.200700.03.2 Handle
1
56
1.6177.1.08 Flange Lock Nut M8
14
57
1.5789.0845 Flange Bolt M8×45
2
58
6.2.263.318.2 Frame
1
59
2.05.001 Clamp (Ø8×6.5)
2
60
122.201200.05 Motor Mount, II
2
61
122.201200.04 Motor Mount, I
2
62
1.6182.10 Lock Nut M10
2
63
122.201701.05.2 8 in. Wheel
2
64
122.200016.01 Bushing (Ø16×Ø10.5×58.5)
2
65
1.96.10 Washer Ø10
2
66
1.5782.10105 Bolt M10×105
2
67
1.5789.0816 Flange Bolt M8×16
2
68
152.200002.00.2 Support Leg
1
69
152.201400.00 Rubber, Support
2
70
1.5789.0825 Flange Bolt M8×25
2
71
1.6177.1.06 Flange Lock Nut M6
1
72
5.1900.026 Grounding Line 150 mm
1
73
1.862.06 Lock Washer Ø6
2
74
2.08.068.2 Flange Bolt M5×13
4
75
122.01.110.2 Control Panel
1
76
5.1000.004.3 Ignition Switch
1
77
5.1400.003 Voltage Meter
1
78
1.848.03.2 Washer Ø3
4
79
1.859.03.2 Spring Washer Ø3
4
80
1.6175.03.2 Nut M3
4
81
5.1120.0 09 Receptacle L14-30R
1
82
1.9074.4.0414.1
Screw And Washer Assembly
M4×14, Black
6
83
1.6177.1.04.1 Flange Lock Nut M4, Black
6
84
5.1020.002
120/240V Change-over
Switch
1
85
5.1120.034 Receptacle TT-30R
1
86
5.1120.030 Receptacle 5-20R
1
87
1.5783.0622.3 Bolt M6×22, Green
1
88
1.6175.06.3 Nut M6, Green
2
89
1.97.1.06.3 Washer Ø6, Green
2
90
1.93.06.3 Spring Washer Ø6, Green
2
91
122.210003.01 Plug, Control Box
1
92
5.1330.001 Sheath, Wire
1
93
122.210003.03 Plug, End Cover
1
94
5.1810.001 Over Voltage Protector
1
95
1.823.0514 Screw M5×14
1
96
5.1210.920
AC 20A Breaker, Push
Button, CSA
1
97
5.1200.215
AC 15A Breaker, Push
Button, CSA
2
98
1.6177.1.05 Flange Lock Nut M5
4
99
254.200015.00.2 Clamp, Wand
2
100
122.210002.02 Control Box
1
101
1.9074.1.0538.2
Screw And Washer Assembly
M5×38
3
102
122.210003.00 Grommet
1
