REV 46577-20140214 22
46577 ENGLISH
# Part Number Description Qty
1
1.5789.0608 Flange Bolt M6×8 5
2
22.061100.00.2 Recoil Starter Cover, Black 1
3
21.061005.00 Recoil Starter Spring
1
4
2.10.003 Rope (Ø5×1550)
1
5
21.061001.01 Recoil Starter Reel
1
6
45.060003.00 Spring, Ratchet
2
7
45.060002.00 Starter Ratchet (Iron)
2
8
45.060009.00 Spring, Ratchet Guide
1
9
45.060007.00 Ratchet Guide
1
10
45.060008.00 Screw, Ratchet Guide
1
11
24.040004.00 Guide Plate Push Rod
1
12
1.5789.0612 Flange Bolt M6×12
8
13
24.080100.01.94 Fan Cover, Green
1
14
24.091100.21 Base, Air Cleaner
1
15
21.061300.00 Recoil Handle
1
16
24.130004.20 Gasket, Air Cleaner
1
17
22.061000.00 Recoil Assembly
1
18
24.091000.21 Air Cleaner Assembly
1
19
26.131000.20 Carburetor
1
20
2.03.016
Washer, Drain Bolt
(Ø10×Ø16×1.5)
2
21
2.02.006 Nut (M14×1.5)
1
22
21.060001.01 Pulley, Starter
1
23
23.080001.00 Cooling Fan
1
24
24.120100.06 Flywheel
1
25
2.11.001 Oil Seal (Ø25×Ø41.3×6)
2
26
2.03.020.1
Washer (Ø6.2×Ø15×0.5),
Black
1
27
21.110100.00 Governor Gear
1
28
23.130100.20 Choke Lever
1
29
21.110013.00 Shaft, Governor Gear
1
30
21.110011.00 Clip, Governor Gear
1
31
22.130003.00 Gasket, Carburetor
1
32
21.110012.01 Bushing, Governor Gear (Iron)
1
33
24.130002.00 Gasket, Insulator
1
34
23.130001.00 Insulator, Carburetor
1
35
23.080600.00 Air Guide, Right Side
1
36
2.01.003 Stud Bolt M6×90
2
37
26.030100.00 Crankcase (200)
1
38
21.127000.02 Oil Level Sensor
1
39
26.010100.00 Cylinder Head (168-2)
1
40
23.050200.00 Connecting Rod
1
41
25.050100.11
Crankshaft (A 200Engine For
Equipment)
1
42
1.276.6205 Bearing 6205
2
43
24.030008.00 Gasket, Crankcase Cover
1
44
22.031000.00.1 Oil Dipstick Assembly, Black
1
45
2.03.021.1 Washer (Ø6.4×Ø13×1), Black
1
46
23.030007.01
Cover, Crankcase (Engine For
Equipment)
1
47
1.5789.0832.0.8 Flange Bolt M8×32
6
48
23.091002.21 Seal, Air Cleaner
1
49
23.110006.00 Governor Rod
1
50
21.110003.00 Governor Arm
1
51
1.6177.0 6 Flange Nut M6
3
# Part Number Description Qty
52
21.110001.00 Shaft, Governor Arm
1
53
22.123000.01
Ignition Coil (Silicon Rubber
EPA)
1
54
1.5789.0625 Flange Bolt M6×25
2
55
23.110005.01 Spring, Throttle Return
1
56
23.110007.00 Spring, Governor
1
57
2.08.040 Bolt, Governor Arm (M6×21)
1
58
21.110008.00 Pin, Shaft
1
59
23.111000.20
Control Assembly (Engine For
Equipment)
1
60
25.040013.00 Lifter, Valve
2
61
2.04.001 Dowel Pin (Ø9×14)
2
62
26.041000.00 Camshaft (200 EPA)
1
63
2.14.012 Woodruff Key (4×7.5×19)
1
64
2.08.037 Drain Bolt (M10×1.25×25)
2
65
26.050005.00 Piston
1
66
23.050003.00 Pin, Piston
1
67
2.09.001 Circlip (Ø18×Ø1)
2
68
26.050303.00 Ring, Oil
1
69
26.050302.00 Ring, Second Piston
1
70
26.050301.00 Ring, First Piston
1
71
26.030009.00 Gasket, Cylinder Head (168-2)
1
72
2.04.003 Dowel Pin (Ø10×14)
2
73
23.040002.00 Valve, Intake
1
74
23.040006.00 Valve, Exhaust
1
75
26.080400.00 Air Guide, Lower (200G)
1
76
2.15.002(F6RTC) Spark Plug (F6RTC)
1
77
1.5789.0855 Flange Bolt M8×55
4
78
23.040017.00 Oil Seal, Valve (Iron)
2
79
21.040003.00 Spring, Valve
2
80
21.040007.00
Retainer, Exhaust Valve Spring
(Up)
1
81
21.040001.00
Retainer, Intake Valve Spring
(Up)
1
82
21.040008.00 Rotator, Exhaust Valve
1
83
24.040202.00 Shaft, Rocker Arm
1
84
22.040009.00 Rocker Arm, Intake Valve
2
85
22.040012.00 Screw, Valve Adjustment
2
86
21.040021.00 Lock Nut (M6×0.5)
2
87
1.97.1.06 Washer Ø6
2
88
1.6177.1.06 Flange Lock Nut M6
2
89
26 .131017. 2 0 Standard Main Jet
1
26.131017.20.01 Altitude Main Jet
/
90
24.040201.00 Retainer, Rocker Arm
1
91
23.040010.00 Bolt, Rocker Arm
2
92
23.040005.00 Push Rod
2
93
21.020002.01 Gasket, Cylinder Head Cover
1
94
24.021000.00 Cylinder Head Cover (CPE)
1
95
23.020001.02 Breather Tube
1
96
1.5789.0615 Flange Bolt M6×15
4
97
2.01.010 Stud Bolt M8×35
2
98
1.5789.0620 Flange Bolt M6×20
1
99
24.091200.20 Cover, Air Cleaner
1
100
23.091003.21 Element, Air Cleaner
1
101
23.091001.21 Separator, Air Cleaner
1
To Next Page
