Cadel GRACE 3 - Main Menu; Settings Menu

GRACE
3
- SPIRIT
3
- TALAS
3
8
LEGEND Fig. 2 - Fig. 3
12 Ambient temperature
13 If there is "." = 0.5 °C (29.° = 29.5°)
8.3 MAIN MENU
It is accessed by pressing key 3 (menu). The items that are accessed are:
• Time and Date
• Timer
• Sleep (only with the stove on)
• Settings
• Info
Date and time setting
To set the date and time act as follows:
• Press the “menu” button.
• Select “Time and Date”.
• Select by pressing “menu”
• Scroll with the arrows and select the variables to be modified one at a time: Day, Hours, Minutes, Day number, Month, Year.
• Select “menu” to confirm.
• Modify with the + - keys.
• Finally press “menu” to confirm and “esc” to exit.
Timer setting (see relative chapter)
Sleep setting (see relative chapter)
8.4 SETTINGS MENU
The SETTINGS menu allows to act on the boiler operating mode:
a - Language
b - Cleaning (displayed only when the boiler is switched off)
c - Screw Loading (displayed only when the boiler is switched off)
d - Tone
e - Ext.Thermostat (activation)
f - Auto-Eco (activation)
g - Off Time Eco (default 5 minutes)
h - Pellet Recipe
i - Smoke Fan rpm
j - Components Test (displayed only when the boiler is switched off)
k - Chimney Sweep Function (activated only when the boiler is switched on, for field emissions test)
l - Technical Menu
a - Language
To select the language act as follows:
• Press the “menu” button.
• Scroll to “Settings” using the arrows
• Press “menu” to confirm.
• Scroll to “Language” using the arrows.
• Press “menu” to confirm.
• With the + - keys select the language of interest (IT/EN/DE/FR/ES/NL/PL/DA/SL)
• Press “menu” to confirm and “esc” to exit.
b - Cleaning
To select “Cleaning” (only when the boiler is switched off) act as follows:
• Press the “menu” button.
• Scroll to “Settings” using the arrows
