Cadillac 2007 CTS User Manual

Wiring
Harnesses
Usage
BODY W/H Wiring Harness Connection
BODY W/H Wiring Harness Connection
ENG W/H Engine Wiring Harness Connection
J Cases Usage
R REAR
RRPDB (Passenger’s Side Rear
Power Distribution Box)
R REAR
RRPDB (Passenger’s Side Rear
Power Distribution Box)
L REAR
LRPDB (Driver’s Side Rear Power
Distribution Box)
L REAR
LRPDB (Driver’s Side Rear Power
Distribution Box)
HI FAN High Cooling Fan Motor
LO FAN Low Cooling Fan Motor
BLOWER PWM Fan Motor Assembly
STARTER Starter Solenoid
ABS Anti-Lock Brake System
Fuses Usage
RT PARK
Passenger’s Side Taillamp
Assembly, Front Sidemarker and
Front Parking Lamp Assembly
HORN Dual Horn Assembly
LT HI BEAM Driver’s Side High-Beam Headlamp
LT LOW BEAM Driver’s Side Low-Beam Headlamp
RT LOW BEAM
Passenger’s Side Low-Beam
Headlamp
RT HI BEAM
Passenger’s Side High-Beam
Headlamp
TOS
Manual Transmission Output Speed
Sensor
SPARE Not Used
THEFT
ECM (Engine Control Module), TCM
(Transmission Control Module),
PASS-Key
®
III+ Module
LT PARK
Driver’s Side Taillamp Assembly,
Front Sidemarker and Front Parking
Lamp Assembly
DIMMING
Rear License Plate Assembly, Dash
Integrated Module (DIM)
DIM/ALDL
DIM, ALDL (Assembly Line
Data Link)
FLASHER Turn Signal/Hazard Flasher Module
ECM Electronic Control Module
