Cadillac 2017 CT6 - Instrument Panel Fuse Block

Cadillac CT6 Owner Manual (GMNA-Localizing-MidEast-9418855) - 2016 -
crc - 12/15/15
274 Vehicle Care
Number Usage
20 High-beam
headlamp relay
21 A/C clutch
22 –
23 Coolant heater
control module
24 Coolant pump
25 Coolant pump relay
26 Hi fuel
27 Steering
column lock
28 Rear heated seats
29 Front heated seats
30 –
31 LED LGT battery
32 A/C control module
33 AIR solenoid
34 –
35 Engine control
module
36 Engine control
module 2
Number Usage
37 Coolant pump/
Ignition coils–odd
38 Ignition coils–even/
Non walk 2
39 Non walk
40 Instrument cluster
41 –
42 Fuel pump power
module
43 Instrument panel
body/Ignition
44 Aeroshutter
45 Washer
46 Front sensor
47 Left cornering LED
48 AIR solenoid relay
49 Air pump relay
50 Engine control
module relay
51 Wiper speed relay
52 Wiper control relay
Number Usage
53 Headlamp control
relay
54 –
55 –
56 Air pump
57 –
58 Instrument panel
electronic center
59 –
60 ABS pump
61 Front wiper
62 Headlamp leveling
63 Electric brake
booster module
64 –
65 –
66 Transfer case
control module
67 Electric brake
booster
