VEHICLE CARE 383
The vehicle may not be equipped with
all of the fuses, relays, and features
shown.
Fuses Usage
F01 RFA
F02 WCM
F03 Heated seat module
row 1 (Batter y 1)
F04 MSM driver
F05 –
F06 –
F07 Amp aux 2
F08 –
F09 SEO UPFTR 2
F10 Motor seatbelt
passenger
F11 Power folding seat
row 2
F12 GBS
F13 –
F14 –
F15 Heated seat module
row 1 (Batter y 2)
F16 RH CINCH latch
Fuses Usage
F17 Memory seat module
passenger
F18 Rear wiper
F19 Motor seatbelt driver
F20 Rear defogger
F21 –
F22 Rear HVAC display
control
F23 EOCM
F24 Amp aux 3
F25 OBS DET
F26 RDCM
F27 Amp aux 1
F28 VPM
F29 –
F30 –
F31 Amp
F32 –
F33 ICCM
F34 Heated seat module
row 2
