10-38 Vehicle Care
A. Turn Signal Lamp
B. Back-Up Bulb/Socket
6. Turn the turn signal lamp (A)
bulb socket counterclockwise
to remove it from the taillamp
assembly.
7. Pull the bulb straight out from
the socket.
8. Press a new bulb into the
socket, insert it into the taillamp
assembly and turn the bulb
socket clockwise until it clicks.
9. Reinstall the taillamp assembly
and tighten the screws.
10. Reinstall the taillamp cover by
snapping it into place.
11. Push the push pin to secure
the taillamp cover.
Back-Up Lamps
To repl a ce one of the s e bulb s :
1. Open the liftgate. See Liftgate
on page 2�14.
A. Push Pin
B. Taillamp Cover
2. Pull on push pin (A) to release
the taillamp cover (B).
3. Remove the taillamp cover from
the lamp assembly by pulling
rearward from the top to
unfasten from snap tabs.
