PN 21157307 A | User Manual 3 - ENG
HELiOS
Specifications
• Mode of Operation: Continuous Flow
• Type of Protection Against Electrical Shock: Internally Powered Equipment
•
Degree of Protection Against Electrical Shock: Type BF Applied Part
• IP21 Classication According to the Degree of Protection Against Ingress of Water: Internal protec-
tion against ingress of solid foreign objects greater than or equal to 12.5 mm in diameter and ingress
of vertically dripping water.
•
Equipment not suitable for use in the presence of ammable mixtures
Product Specifications
HELiOS U36 HELiOS U46 HELiOS 36 HELiOS 46
LOX capacity 85 lb
(38,6 kg)
110 lb
(49,9 kg)
85 lb
(38,6 kg)
110 lb (49,9 kg)
Gaseous equivalent
capacity
29,069 L 37,916 L 29,069 L 37,916 L
Weight, filled 138 lb (62,6 kg) 170 lb (77,1 kg) 138 lb (62,6 kg) 170 lb (77,1 kg)
Weight, empty 53 lb (24 kg) 60 lb (27,2 kg) 53 lb (24 kg) 60 lb (27,2 kg)
Height 33.5 in. (851 mm) 37.5 in. (952 mm) 33.5 in. (851 mm) 37.5 in. (952 mm)
Diameter 15.4 in. (391 mm) 15.4 in. (391 mm) 15.4 in. (391 mm) 15.4 in. (391 mm)
Typical use time at 2
LPM demand mode
10 days
21 hrs
13 days
21 hrs
10 days
21 hrs
13 days
21 hrs
Operating pressure 22 psi (152 kPa) 22 psi (152 kPa) 22 psi (152 kPa) 22 psi (152 kPa)
Normal evaporation
rate
1.2 lb/ day (0,54
kg/day)
1.2 lb/ day (0,54
kg/day)
1.2 lb/ day (0,54
kg/day)
1.2 lb/ day (0,54
kg/day)
Standard flow control
range
Maximum flow 10
LPM
Maximum flow 10
LPM
Maximum flow 10
LPM
Maximum flow 10
LPM
Flow Rate Accuracy*
* This accuracy is only at 70F and 14.7 psig and with a calibrated accurate mass ow meter.
