U SER ’ S G UIDE — 59
Angle and Diagonal (Hypotenuse)
Find the Diagonal (Hypotenuse) and degree of angle of a right trian-
gle that is 9 Feet high and 12 Feet long.
KEYSTROKE DISPLAY
1. Enter Rise and Run:
o o 0.
9 f r RISE 9 FEET 0 INCH
1 2 f R RUN 12 FEET 0 INCH
2. Solve for Diagonal/Hypotenuse and Pitch in Inches and Degree of
Angle:
d DIAG 15 FEET 0 INCH
p PTCH 9 INCH
p PTCH 36.87°
Rise
Find the Rise given a 7/12 Pitch and a Run of 11 Feet 6 Inches.
KEYSTROKE DISPLAY
o o 0.
7 i p PTCH 7 INCH
1 1 f 6 i R RUN 11 FEET 6 INCH
r RISE 6 FEET 8-1/2 INCH
Rise and Diagonal
Find the Rise and Diagonal of a right triangle given a 30° Pitch and
a run of 20 Feet 4 Inches.
KEYSTROKE DISPLAY
o o 0.
3 0 p PTCH 30.00°
2 0 f 4 i R RUN 20 FEET 4 INCH
r RISE 11 FEET 8-7/8 INCH
d DIAG 23 FEET 5-3/4 INCH
