44 — Construction Master IV
Raked Wall – Stud Sizes
Find each stud size in a raked wall
with a peak of 15 feet 5 inches, and a
length of 30 feet 7 inches. Use 16
inches as your on-center spacing.
Keystroke Display
[On/C] [On/C]
0.
Enter Rise, Run and O.C. Spacing
15 [Feet] 5 [Inch] [Rise]
RISE 15 FT 5 IN
30 [Feet] 7 [Inch] [Run]
RUN 30 FT 7 IN
16 [Inch][Conv] [Diag]
OC 16 IN
Find Stud Lengths
[Conv] [Diag]
RW 1 14 FT 8-15/16 IN
[Diag]
RW 2 14 FT 0-7/8 IN
[Diag]
RW 3 13 FT 4-13/16 IN
[Diag]
RW 4 12 FT 8-3/4 IN
[Diag]
RW 5 12 FT 0-11/16 IN
Etc......Continue pressing [Diag] until
last stud size or "0" is reached.
