Page 29
NOTES: Connect supply wiring as shown in the diagrams above.
Connect only to a circuit which is protected by a RCD (Residual Current Device).
KAUAI
TB1
2
2
2
2
2
2 2
22
N,
20 Amp
220-240VAC
4.0 MM
4.0 MM
L,
#8AWG 10.0MM
16 AMP
4.0 MM
N,
L,
4.0 MM
GND
(10.0 MM ) (10.0 MM )
(10.0 MM )
(32 AMP)
(10.0 MM )
(40 Amp)
Electrical Requirements
HOT,
HOT,
NEUTRALNEUTRAL
GROUND,
RCD BREAKER
7
2
3
4
5
6
8 1
EQUIPMENT COMPARTMENT
The illustration below is to be used as a reference only (your spa may look different). The equipment compartment is located behind the front panel of the
spa below the Main Control Panel.
1. Jet pump*
2. EnergyPro
®
heater
3. ENERGY PRO Circulation Pump
4. Advent
®
Control Box
5. Ozone Generator (optional)
6. Bonding terminal
7. Bluetooth Music (optional)
8. Subwoofer (optional)
1
