Installation
WARNING!
Disconnect negative battery terminal from battery
before starting installation. Consult the vehicle’s
owner’s manual for proper instructions.
NOTE:
Mark the polarity of the existing speaker wires before
disconnecting battery.
NOTE: Remove the two transport screws from the top of the
unit before installing.
1. After removing the old
radio and mounting sleeve,
insert supplied mount-
ing sleeve into opening.
2. Bend the tabs on the mount-
ing sleeve to keep the mount-
ing sleeve firmly in place.
3. Attach wires from the unit to
existing wires. See wiring con-
nections diagram. Insert radio
into dashboard. Then apply the
trim frame to outside of radio.
4. Support radio using sup-
plied rear mounting bolt
and steel bar. See parts list.
DIN Front Mount
