9
CART HANDLE ADJUSTMENT
• To adjust the angle of the cart handle, loosen (rotate counterclockwise) the black knob with the
Callaway Chevron located near the upper bag holder.
• Adjust the handle to the desired angle and rotate the knob clockwise to tighten
• Caution: When adjusting the handle, loosen the knob enough so there is a space between the
“teeth” on the cart handle. If the knob is not loosened enough, the “teeth” can wear and cause
adjustment issues.
SECURING BAG TO CART
• One end of the straps has a loop and the other end has a plastic ball attached. The loop goes
around the ball to secure your bag using tension.
• There is an upper bag strap and a lower bag strap.
• The bottom of your golf bag rests on the 2 angled frame pieces which have a plastic ball
attached to the ends.
• If you need more tension on the bag straps to hold your bag in place, tie knots in the straps to
increase the amount of tension.
REMOTE MOUNT
• On the back of the cart handle, there is a plastic “ring”. If you would like to secure the remote to
the cart, the remote clip can slide into the “ring” for convenient remote placement.
• Store remote control in closable compartment when the remote is not in use & during transportation.
TRANSPORTATION
• Fold the handle down & tighten the adjustment knob
• Securing arm to cart:
• With the cart handle folded down, use the lower
bag strap (the end with the ball attached) & loop
around the upper bag holder
• Secure bag strap loop to the silver ring mounted
on the cart frame. The silver ring is located in
front of the cart battery.
• Removing wheels: removing the wheels and wheelie
bar for transportation is based upon the users’ needs.
