THERMOSIPHONIC SOLAR WATER HEATERS / TECHNICAL DOCUMENTATION / PAGE 11
STEP 6
Ensure that the distance B between the centres of the tank support holes is in accordance with Table
B. If there is deviation you may make small adjustments ensuring that both pillars are vertical and that
the collector is centered between them.
TABLE Β
TANK 125/160 L 200 L 300 L
DISTANCE Β [mm] 1090 1378 1842
STEP 7
Tighten the 4 collector securing bolts.
