THERMOSIPHONIC SOLAR WATER HEATERS / TECHNICAL DOCUMENTATION / PAGE 28
VII) HYDRAULIC CONNECTION OF SYSTEM [All systems]
STEP 1
Connect the cold water supply tube and the safety and non return valve onto the tank. To save time
you may start filling the tank at this point. When water starts overflowing from the hot water open
circuit outlet close the water supply.
STEP 2
Connect the hot water closed circuit tube between the collector and the tank. Ensure that the tube
follows an upwards route towards the tank. When tightening the fittings on the collector exit make
sure you use 2 spanners, 1 for tightening and 1 against to avoid damaging the absorber.
