IMPULSE
CONTENTS
Start Up Guide 5
Getting Started 6
Checklist 6
1. Power up the Impulse Cores & connect a PC 7
2. Access the basic core configuration 8
Calrec Configure Login Instructions 8
3. Configure the Surface IP Connections 10
4. Connect the Surface to the Impulse Cores 11
Surface Ethernet Switches 11
5. Power up the Surface & create a new show 12
6. Configure Network Switches & Devices 13
7. Access Configure, Connect, Software Updater & Assist 15
8. Update the Core Software to the latest version (Optional) 16
9. Configure AoIP Core Router Ports & AoIP I/O Devices 17
Calrec Connect Login Instructions 18
10. Connecting the Audio Switch and AoIP Devices to the Core 28
11. Understanding Synchronisation 29
12. Examine an example system (Surface+Cores+Devices) 32
13. Navigate the Console & Perform System Tests 34
Surface Panel Overview 34
Layer Navigation 35
Mode Navigation 35
Mode Row Sets 36
Other Argo Panels 37
Basic System Tests 37
DSP Pack Comparison 38
DSP Pack Sizes for Argo S & Argo Q 38
DSP Packs & Multiple Mixers 40
Primary Core - Router Interfaces - Suggested Settings 41
Secondary Core - Router Interfaces - Suggested Settings 42
AoIP Devices - Network Interfaces - Suggested Settings 43
Further Reading - Impulse 44
User Notes 45
