PMP 400/430 and PTP 200/230 Series Configuration and User Guide
pmp-0042 (March 2014) Page 40 of 98
Table 9: 5.8 GHz Channel Center Frequencies, by Region
Channel
Bandwidth
Region(s)
Range of Center
Frequencies
Available (MHz)
Center
Channel
Spacing
# of
center
channels
# of non-
overlapping
channels
5 MHz
United States,
Canada, Australia,
Brazil and Russia
5727.5 – 5847.5 2.5 MHz 49 25
Europe and Other 5727.5 – 5872.5 2.5 MHz 59 30
India 5827.5 – 5872.5 2.5 MHz 19 10
Vietnam 5727.5 – 5847.5 2.5 MHz 49 25
Indonesia 5727.5 – 5822.5 2.5 MHz 39 20
10 MHz
United States,
Canada, Australia,
Brazil and Russia
5730 – 5845 5 MHz 24 12
Europe and Other 5730 – 5870 5 MHz 29 15
India 5830 – 5870 5 MHz 9 5
Vietnam 5730 – 5845 5 MHz 24 12
Indonesia 5730 – 5830 5 MHz 21 11
20 MHz
United States,
Canada, Australia,
Brazil and Russia
5735 – 5840 5 MHz 22 6
Europe and Other 5735 – 5865 5 MHz 27 7
India 5835 – 5865 5 MHz 7 2
Vietnam 5735 – 5840 5 MHz 22 11
Indonesia 5735 – 5815 5 MHz 17 9
20 MHz FSK
(for
comparison)
United States,
Canada, Europe
and Australia
5735 – 5840 5 MHz 22 6
(For reference, standard Canopy uses 2-channel re-use with clusters of 6 APs on a tower with channel
center spacing of either 25 MHz for Advantage APs or 20 MHz for non-Advantage APs. This is ABCABC
channel planning, with 5 MHz guard band between the 20 MHz channels for Advantage APs and no guard
band needed for non-Advantage.)
Available 5.4 GHz channel center frequencies for each region are shown in Table 10. These vary by region
due to
 different band edge RF specifications (for example, between Canada/US and Europe)
 requirements in US, Canada, Europe and Australia to not impinge on the frequencies between
5600 and 5650 MHz, which are frequencies on which some weather radar operate
