Cambium Networks PMP/PTP 450i Series User Manual

Chapter 2: System hardware System Components
Page 2-26
Power (green) LED
Power supply detection
Ethernet (yellow) LED
Ethernet traffic detection
The DC Power Injector interfaces are shown in Figure 12 and described in Table 23.
Figure 12 -48 V DC Power Injector interfaces
Table 23 -48V DC Power Injector interfaces
Interface
Function
DC input
36 to 60V, 2A
RJ 45 Sockets
Two (Data In and Data & Power Out)
LEDs
Two (AC and Port)
Power supply – PMP/PTP 450
The PMP/PTP 450 support powering from the following powering sources:
• Gigabit Enet Capable Power Supply - 30VDC, 15W
• Power Supply,120W 30VDC AT 60C 100-240VAC EL5
Table 24 PSU part numbers for PMP/PTP 450
