Chapter 2: System hardware System Components
Page 2-27
Gigabit Enet Capable Power Supply - 30VDC, 15W
Power Supply,120W 30VDC AT 60C 100-240VAC EL5
The Gigabit Enet Capable power supply interfaces are described in Table 25. Table 25 –Gigabit
Enet Capable power supply
90-264 VAC, 0.5A rms @120VAC/ 0.25A rms @240VAC, 47 to 63 Hz
30.0 Vdc +/-5%, 15W, 500 mA max
Two (Data In and Data & Power Out)
Green, :LED Intensity determined by Level 5 efficiency
The power supply 120W/30VDC interfaces are described in Table 26.
Table 26 -120 W/30 VDC power supply
90-264 VAC, 3A rms @115VAC/ 1.5A rms @230VAC, 47 to 63 Hz
30.0 Vdc +/-5%, 120W, 4 A max
Two (Data In and Data & Power Out)
ODU mounting brackets & accessories
The list of supported brackets is provided in Table 27.
• The "Tilt bracket assembly" is the recommended bracket for the AP, SM or BH integrated units.
