PMP Synchronization Solutions User Guide Installing the CMM5
PMP-0297 007v001 (January, 2017)
2-42
Installing a Controller/Injector side by side
Perform the following procedure to install a Controller/Injector combination.
Procedure 4 Installing a Controller/Injector Combination
1
Ensure that the following hardware is available:
• (2) standard mounting ears for a 19-inch rack
• (2) spacers
• (4) mounting screws for each mounting ear
• (1) joining bar (w/attaching hardware)
• (1) joining screw (mounted in rear)
2
Use 4 mounting screws to secure the mounting ear to the Injector.
3
Use 2 mounting screws to secure the other end of the mounting ear to the rack.
4
Attach the joining bar (with hardware) as shown.
5
Install the rear joining screw as shown.
