PTP 820C/820S PoE Injector Installation Instructions
phn-4013 001v000
3
1
Drill two 6mm diameter holes, with 100mm between the center of the holes.
2
Insert the anchors with the bolts.
3
Place the washers on the bolts.
4
Tighten the nuts.
5
Mount PoE Injector to Wall
Caution
For the warranty to be honored, you must install the unit in accordance with the
instructions above.
