Chapter 10: Synchronization
Configuring 1588 Boundary Clock
phn-3965_006v002
Page 10-18
Grandmaster Clock Accuracy
The clock accuracy of the current grandmaster. The clock
accuracy is one of the elements of the clock quality, as
defined in IEEE-1588.
Grandmaster Offset Scaled Log
Variance
The offset scaled log variance of the current grandmaster.
The offset scaled log variance is one of the elements of the
clock quality, as defined in IEEE-1588.
The Priority 1 value of the current grandmaster.
The Priority 2 value of the current grandmaster.
Current UTC Offset (Seconds)
The current UTC offset value (in seconds).
Indicates whether the current UTC offset value is valid.
Indicates that the last minute of the current UTC day
contains 59 seconds.
Indicates that the last minute of the current UTC day
contains 61 seconds.
Traceability to the primary time reference.
Traceability to the primary frequency reference.
Indicates whether the clock time scale of the grandmaster
clock is PTP.
The source of the time used by the grandmaster clock.
Displaying the Boundary Clock Port Parameters
To display the Boundary Clock port parameters:
1. Select Sync > 1588 > Boundary Clock > Port Parameters. The 1588 Boundary Clock – Port Parameters page
opens.
2. Select the port you want to configure and click Edit. The 1588 Boundary Clock – Port Parameters – Edit page
opens.
For an explanation of the configurable fields, see Enabling Boundary Clock. The Following Table describes the
Boundary Clock Port Parameters,
Table 117 Boundary Clock Port Parameters.
ThePTP 820 unit’s clock identity. The same value is used for
every port that belongs to the Boundary Clock node.
In this version, displays 1 for every port.
