Advanced settings (V4 Pro)
⚠
ISO
Set the light sensitivity :
• Auto*
• 100
• 200
• 400
• 800
• 1600
• 3200
• 6400
Saturation
Set the color intensity :
• 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12*, 13, 14, 15, 16, 17, 18
0 = black & white ; 18 = warm colours
The * symbol indicates the default factory settings of the Cambox
* Advanced features in Pro Mode are only available
on the Cambox V4 Pro model
25
Contrast
Set the contrast intensity :
> 0, 1, 2, 3, 4*, 5, 6, 7, 8, 9, 10
Sharpness
Set the image sharpness level :
• 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12*, 13, 14
Edge Strength
Set the image grain level :
> 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12*, 13, 14
