Cambridge Audio 640C V2 Service Manual

AP17519/3
AP Part
No
Value Description Qty Component Ident Factory Part No Notes
82R 0.25W 1% Metal Film Resistor 1 R20 1011-002014-000
100R 0.25W 1% Metal Film Resistor 2 R15 1011-001014-000
220R 0.25W 1% Metal Film Resistor 2 R1, 14 1012-201014-000
1K5 0.25W 1% Metal Film Resistor 1 R8 1011-502014-000
2K2 0.25W 1% Metal Film Resistor 1 R18
2K7 0.25W 1% Metal Film Resistor 1 R5 1012-702014-000
3K3 0.25W 1% Metal Film Resistor 1 R11 1013-302014-000
4K7 0.25W 1% Metal Film Resistor 3 R12, 16, 19 1014-702014-000
5K6 0.25W 1% Metal Film Resistor 2 R2, 17
10K 0.25W 1% Metal Film Resistor 3 R6, 13, 22 1011-003014-000
27K 0.25W 1% Metal Film Resistor 1 R3 1012-703014-000
33K 0.25W 1% Metal Film Resistor 1 R4 1013-303014-000
68K 0.25W 1% Metal Film Resistor 1 R10 1016-803014-000
82K 0.25W 1% Metal Film Resistor 2 R7, 9 1018-203014-000
200R
BOCHEN 3296P side adjst MULTI
turn pot
1 R21
*Revised
1nF Ceramic 50V 10% 5mm pitch 2 C2, 3 1100-102043-000
100n Ceramic 50V X7R 10% 5mm pitch 2 C1, 4
10uF 25V Radial Electrolytic, 20%, 1 C5, 6 1102-100024-000
PY214 BC337-25 NPN small signal transistor TO-92 3 Q1, 3, 4 1300-337000-100
PY219 BC327-25 PNP small signal transistor TO-92 1 Q2 1301-327000-100
PY054
TSOP1836SS
3V
IR Receiver module (VISHAY) 1 U2 3001-183600-001
PIC16C505 Microchip 14 pin 8 Bit PIC 1 U3 4116-505054-200
Programmed with:
AP18402/1 640CV2 V1.0.hex
PD012 1N5819 Schottky diode 1 D1
PY064 Blue LED 3mm Blue flat top LED 1 D2 3100-000030-003
PY043 Tact switch TACT SW 2P2T KPT-1105A (5MM) 6 SW1, 2, 3, 4, 5, 6 2400-020200-000
PY936 AP17522/1 Positive LCD for V2 1 LCD1 RCL IS06635P00V0
AP13344/* LCD holder 1
PY806 LCD back light assembly 1
Semiconductors
Miscellaneous
* PLEASE NOTE: All components that appear in Red or Bold are additional items to this Bom AP17519/3 and will not appear on AP17519/2.
Cambridge Azur 540C/640C V2 Front Panel PCB Assembly BOM - Revised
Resistors
Capacitors
Transistors
Note: resistors, capacitors and other 'generic'electronic components are
not usually stocked by the manufacturer. Please obtain these locally.
10
