Cambridge Audio 640C V2 Service Manual

AP17616/3
AP PART
NO
VALUE DESCRIPTION QTY
COMPONENT
IDENT
FACTORY PART
NO
NOTES
Cambridge Azur 640C V2 DAC PCB Assembly BOM
100n NPO/C0G radial ceramic 14
C7, 23, 26, 27, 28, 70,
81, 89, 97, 104, 105,
108, 109, 111, 112
5MM PITCH
100n NPO/C0G radial ceramic 100V 3 C1, 2, 3 5MM PITCH (Must be 100V)
4.7uF 50V Radial Electrolytic Capacitor 1 C29 1102-477044-000 5.2MM DIAMETER
10uF NP 25V Radial Non-polar Electrolytic 4 C63, 66, 74, 84 1105-100024-000 5.2MM DIAMETER
10uF 16V Radial Electrolytic Capacitor 2 C106, 110 5.2MM DIAMETER
47uF 25V Radial Electrolytic Capacitor 3 C5, 29, 98 1102-470024-000 5.2MM DIAMETER
100uF NP 16V Radial Non-polar Electrolytic 2 C30, 35 1105-101024-000 8.4MM DIAMETER
330uF 16V Radial Electrolytic Capacitor 4 C64, 69, 75, 88 8.4MM DIAMETER
1000uF
25V Radial Electrolytic Capacitor 105
degree C
2 C21, 91 10.4MM DIAMETER
4700uF 35V Radial Electrolytic Capacitor 2 C96, 100
D = 18MM, P = 8MM, H =
35MM
PD008 1N4004 Standard rectifier diode 3 D1, 9, 10 1401-140040-000
SB1H100 schottky diode 1A 100V 4 D2, 3, 4, 5,
PD009 1N4148 Standard signal diode 2 D6, 7 1401-141480-000
PY962 MV50640 Fairchild 3mm DIA Red LED 1 D10
Fitted as part of assembly with
AP17339/3
No alternative to used
C8050 Small signal transistor NPN, TO92 2 Q2, 4 1300-805000-100
C9012 Small signal transistor PNP, TO92 2 Q1, 3 1301-901200-100
PY214 BC337 Small signal transistor NPN, TO92 1 Q5 1300-337000-100
PD035 7805 5V, 1A regulator, TO220 7 U1, 8, 9, 11, 12, 17, 21 4178-050334-700
PD037 7815 15V, 1A regulator, TO220 1 U3 4178-150301-800
PD038 7915 -15V, 1A regulator, TO220 1 U2 4179-150302-600
PY585 WM8740 24-bit Stereo DAC 2 U7, 10 4187-400990-000 Wolfson
PY108 NE5532 Audio Op-amp 6 U4, 5, 6, 13, 18, 19 4155-320052-900 texas instrument
PY343 74HC14 HCMOS DIL 2 U20, 22 4174-140052-900 texas instrument
PY363 APTX179A Opto TX 1 U23 4117-900990-000
PY054 TSOP1836 IR Receiver 1 U14
CD4011BE
Texas Instruments Quad NAND gate
IC
1 U16
Alternative is National semi
CD4011BCN
PD025 OP4N25 Opto-isolator IC 1 U15
MISC
PY028 16.934MHz XTAL Oscillator module, 4 pin 1 X1 1600-169343-602 Half size 50ppm
Copper plated screening can & logo 1
Fit over clock circuit
(over X1)
6540-010221-000 Copper plated
AP17339/3 IR Receiver housing 1 Fit over D8, 14
PY584 Relay 5V SS-DPDT 1 RL1 4050-000005-002 DS2Y-S-DC5V
Single RCA connector, gold
plated,BLACK INSERT
1 CN5 AV-8,4-8ES (COAX OUT)
Dual RCA connector, gold plated,
RED( bottom) & WHITE(top)
1 CN6
AV2-8,4-13EL (AUDIO LINE
OUT)
Dual RCA connector, gold plated,
ORANGE insert
1 CN8 AV2-8,4-14EC
3.5mm JACK 1 CN7 CKX-3.5-12
CONNECTORS
SEMICONDUCTORS
Note: resistors, capacitors and other 'generic' electronic components are not usally stocked
by the manufacturer. Please obtain these locally.
25
