S-Series Technical Manual 13 Cambridge Engineering, Inc.
STAND DETAIL
RAIN HOOD
ADJUSTABLE MOUNTING STAND
EXTERNAL GAS TRAIN WITH ENCLOSURE
ELECTRICAL JUNCTION BOX
(APPLICABLE TO SOME FM AND XL GAPS OPTIONS)
ELECTRICAL CONTROL ENCLOSURE
(PROVIDED WITH EXTERNAL GAS TRAIN)
MOUNTING RAIL
FILTER SECTION
UNIT
DOWNTURN
(OPTIONAL)
ELBOWS
DIRECTIONAL
INTERIOR WALL TRIM
(BY OTHERS)
WALL SLEEVE
(BY OTHERS)
EXTERIOR WALL TRIM
TYPICAL INSTALLATION
ROOF TOP / THRU WALL MOUNTING
10½"
12"
2 X 4 TREATED LUMBER
(PROVIDED)
2 X 6 TREATED LUMBER
(BY OTHERS)
TREATED LUMBER
(BY OTHERS)
