CAME FTL Series User Manual

1
9
5
4
11
10
7
8
3
12
13
15
2
14
6
16
327
165
272
64
118
100
35
60
100
18
p. 6 - Manual FA00995-EN - 01/2018 - © CAME S.p.A. -
Translation of the original instructions
Description of parts
1. Cover
2. Board protecting cover
3. EMC02 card
4. Post brace
5. Gear motor
6. Mechanical stop
7. Release lever
8. Lock
9. Board-fitting support
10. Board-housing
11. Control board
12. Transmission arm protection
13. Transmission arm
14. Joint arm
15. Gate brace
16. Release keys
Dimensions
UNI 5931 M8 x 80 2
UNI 5931 M8 x 20 2
UNI 5739 M10 x14 1
UNI 5739 M6 x 10 2
UNI 6955 3.9 x 9.5 1
UNI 6955 3.9 x 13 1
Ø 10 x 39 1
UNI 6593 Ø 6 2
UNI 6592 Ø 12 1
Ø 10 x 45 1
Ø 12 x 26 1
UNI 7474 M8 2
UNI 5588 M8 2
