TECHNICAL DATA
Product number: CLDROPB4(WH)
Product type: LED wash light
Type: Outdoor spotlight
Colour spectrum LED: RGBWA+UV
Number of LEDs: 4
LED type: 15 W Prolight LED
PWM frequency: 800 Hz
Beam angle: Beam Angle 22° / Field Angle 38°
1. Filter Medium BA 32°
2. Filter Wide BA 45°
DMX input: W-DMX
™
(Wireless DMX)
DMX output: –
DMX mode: 20-channel / 2 x 13-channel / 7-channel / 6-channel / 4-channel / 3-channel
DMX functions: Dimmer, dimmer fine, RGBWA+UV fine, strobe, dimmer curves, CCT, dimmer
response, colour macros, colour change, colour fading, DMX delay
Standalone functions: Static, colour macros, auto program, user colour
Control: W-DMX
™
, IR remote control (optional)
Operating controls: Menu, Enter, Up, Down, Power
Display elements: OLED display
Operating voltage: 100 – 240 V AC / 50 – 60 Hz
Power consumption: 75 W
Light intensity (@ 1 m/ 3 m): 6750 lx / 755 lx
Luminous flux: 1400 lm
CRI: White LED >79
Power supply connection: Low-voltage socket for external power supply
Ambient temperature (in operation): 0°C to 40°C
Protection class: IP65
Power supply certificate: CE, RoHS, ETL, FCC
Housing material: Metal
Housing colour: Black / white
Housing cooling: Convection cooling (fanless)
Dimensions (W x H x D, without bracket): 170 x 170 x 186 mm
Weight: 3.1 kg
Additional features: Included: 2x filters and 1x mounting bracket supplied
Optional: 1x external power supply with 6-outlet adapter, IR remote control
