6
TC-003001-30 / Rev 01
Feb-02
Table 1 – Parts List for Standard Gearless Valve
Item
Qty
Description
111
1
Body
112
1
Tailpiece
113
1
Lower Cover Plate
114
1
Adapter Plate
121
*
Body Studs
123
*
Body Nuts
124
*
Cap Screws – Lower Cover Plate/ Adapter Plate
132
1
Trunnion Bearing
134
1
Lower Stem Bearing
135
1
Upper Stem Bearing
146
1
Stem Key
151
1
Nameplate (Not Shown)
153
2
Caution Tag (Not Shown)
161
2
Grease Fitting
162
2
Check Valve
163
1
Stem Grease Fitting
171
1
Bleed Fitting
184
3
Torque Pin
185
1
Locating Torque Pin
211
1
O-Ring, Tailpiece
212
1
BACK-UP RING, TAILPIECE (Only For Class 1500 & 2500)
221
2
O-Ring, Stem
222
2
Back-Up Ring, Stem
224
1
O-Ring, Lower Cover Plate
225
1
BACK-UP RING, LOWER COVER PLATE (Only For Class 1500 & 2500)
231
2
O-Ring, Seat, Outer
232
2
Back-Up Ring, Seat, Outer
233
2
O-Ring, Seat, Inner
241
1
Stem Thrust Washer
241b
1
BALL THRUST WASHER (Only For 6” 900/1500 And All 8”Through 16”)
311
1
Ball
312
1
Trunnion
321
1
Stem
322
*
Stem Retaining Screw
323
2
Ball Drive Pin
325
*
Pipe Plug
330
2
Seat Assembly
341
2
Seat Spring
351
1
Ground Spring
*Quantities depend on valve size and class. Customer assembly drawings available upon request shall specify
quantities.
