Cameron WKM User Manual

TOV
Installation, Operation and Maintenance Manual 10 WKM-TOV-IOM
Valve
Bolt Circle
Dia. (in)
Bolt Size
Lug Body
Size
Class
Qty.
Stud length
"A" (in.)
Cap screw length
"B" (in.)
16"
150
21.25
1-8 UNC
32
4.17
3.04
300
22.50
1 1/4-8 UN
32
5.73
4.36
8
4.71
3.34
600
23.75
1 1/2-8 UN
32
7.54
5.92
8
6.32
4.70
18"
150
22.75
1 1/8-8 UN
28
4.77
3.51
4
3.83
2.57
300
24.75
1 1/4-8 UN
40
5.86
4.49
8
4.83
3.46
600
25.75
1 5/8-8 UN
32
8.24
6.49
8
6.78
5.03
20"
150
25.00
1 1/8-8 UN
32
5.02
3.68
8
3.95
2.62
300
27.00
1 1/4-8 UN
40
6.06
4.61
8
5.04
3.59
600
28.50
1 5/8-8 UN
40
8.56
6.74
8
7.19
5.36
24"
150
29.50
1 1/4-8 UN
32
5.32
3.87
8
4.41
2.96
300
32.00
1 1/2-8 UN
40
6.92
5.22
8
5.70
4.00
600
33.00
1 7/8-8 UN
40
9.59
7.51
8
8.02
5.94
