Cameron WKM User Manual

TOV
Installation, Operation and Maintenance Manual 7 WKM-TOV-IOM
Disc Protrusion length inside pipe
LUG DESIGN
ISO DESIGN
PPE - PREFERRED PRESSURE END
NPPE - NON PREFERRED PRESSURE END
PPE
NPPE
SIZE
CLASS
LUG DESIGN
ISO DESIGN
LP DESIGN
PROTRUSION
ON PPE
SIDE- "A"
(mm)
PROTRUSION
ON NON PPE
SIDE- "B'
(mm)
PROTRUSION ON
PPE SIDE- "X"
(mm)
PROTRUSION ON
NON PPE SIDE- "Y'
(mm)
PROTRUSION ON
PPE SIDE- "M"
(mm)
PROTRUSION ON
NON PPE SIDE- "N'
(mm)
3"
150
21
8
NO PROTRUSION
NO PROTRUSION
NO PROTRUSION
NO PROTRUSION
300
18
11
NO PROTRUSION
NO PROTRUSION
NO PROTRUSION
NO PROTRUSION
4"
150
32
13
NO PROTRUSION
NO PROTRUSION
NO PROTRUSION
NO PROTRUSION
300
28
17
NO PROTRUSION
NO PROTRUSION
NO PROTRUSION
NO PROTRUSION
600
25
10
NO PROTRUSION
NO PROTRUSION
-
6"
150
48
32
4
NO PROTRUSION
NO PROTRUSION
NO PROTRUSION
300
48
32
4
NO PROTRUSION
NO PROTRUSION
NO PROTRUSION
600
23
38.0
NO PROTRUSION
NO PROTRUSION
-
8"
150
69
47
20
10
NO PROTRUSION
NO PROTRUSION
300
63
44
20
10
NO PROTRUSION
NO PROTRUSION
600
46.5
34.5
NO PROTRUSION
NO PROTRUSION
-
10"
150
91
72
39
31
NO PROTRUSION
NO PROTRUSION
300
85
66
39
31
NO PROTRUSION
NO PROTRUSION
600
61.5
51.5
NO PROTRUSION
NO PROTRUSION
-
12"
150
107
86
53
44
NO PROTRUSION
NO PROTRUSION
300
101
80
53
44
NO PROTRUSION
NO PROTRUSION
600
80.0
57.0
9.0
NO PROTRUSION
-
14"
150
119
95
66
52
NO PROTRUSION
22
300
106
84
66
53
NO PROTRUSION
NO PROTRUSION
600
80
66
11.5
1
-
16"
150
139
118
79
66
NO PROTRUSION
44
300
123
104
79
67
NO PROTRUSION
15
600
96
76
25.5
15.5
-
18"
150
166
136
104
92
NO PROTRUSION
63
300
143
124
104
92
NO PROTRUSION
28
600
111.0
88.0
41.0
30
-
20"
150
179
151
120
111
NO PROTRUSION
75
300
159
139
120
111
NO PROTRUSION
30
600
119.5
99.0
48.5
38.0
-
24"
150
221
184
154
142
NO PROTRUSION
109
300
154
142
154
142
NO PROTRUSION
66
600
156
138
74
64
-
NPPE
PPE
LP DESIGN
PPE
NPPE
